Clutch BN4, BN6, BN7, BT7, BJ7 and BJ8
clutch - identified by 10 splines and 55 mm shaft length
Required: 1
with 9" diameter and 10 splines
BN4 and BN6
Required: 1
with 10" diameter
BN7 and BT7 (1959-63), BJ7 to engine no. 29F-H4878
Required: 1
with 9.5" diameter
BJ7 from engine no. 29F-H4878, BJ8 to engine no. 29K-4107
Required: 1
with 9" diameter and 10 splines
BJ8 from engine no. 29K-4108
Required: 1
coil spring type with 9" diameter
BN4 and BN6
Required: 1
with 10" diameter
BN7 and BT7 (1959-63), BJ7 to engine no. 29F-H4878
Required: 1
diaphragm type for 9.5" clutch plate
BJ7 from engine no. 29F-H4878, BJ8 to engine no. 29K-4107
Required: 1
diaphragm type for 9.5" clutch plate
BJ8 from engine no. 29K-4108. Please note: needs modification to the dowel arrangements or with the fitting of one of our steel flywheels
Required: 1
for 10 ” clutch
BN7 and BT7 (1959-63), BJ7 to engine no. 29F-H4878
Required: 1
for 9" and 9.5" clutch - standard version with 7 mm usable lining thickness
BJ7 from engine no. 29F-H4878 plus all BJ8 (1963-67) • can also be used on all BN2 to BJ8 models if fitting a 9.5" clutch
Required: 1
for 9" and 9.5" clutch - competition version with 5 mm usable lining thickness
BJ7 from engine no. 29F-H4878 plus all BJ8 (1963-67) • can also be used on all BN2 to BJ8 models if fitting a 9.5" clutch
Required: 1
clutch
Required: 1
Required: 1
clutch cover - separately
BN4 and BN6
Required: 1
clutch cover - separately
All BN7 and BT7, BJ7 to 29F-H4878
Required: 1
clutch cover - colour code: yellow
BN4 to 48862
Required: 3
clutch cover - colour code: black
BN4 to 48862
Required: 6
clutch cover - colour code: white
BN4 from 48863, all BN6
Required: 6
clutch cover - colour code: black
BN4 from 48863, all BN6
Required: 3
clutch cover - colour code: yellow
All BN7 and BT7, BJ7 to 29F-H4878
Required: 12
release bearing
All BN4, BN6, BN7 and BT7, BJ7 to 29F-H4878
Required: 1
thrust plate
All BN4, BN6, BN7 and BT7, BJ7 to 29F-H4878
Required: 3
release lever
All BN4, BN6, BN7 and BT7, BJ7 to 29F-H4878
Required: 3
BN4 and BN6
Required: 3
for release lever in clutch cover
All BN4, BN6, BN7 and BT7, BJ7 engine no. to 29F-4878
Required: 3
pedal shaft
Required: 1
clutch pedal
Required: 1
All BN4 and BN6, BN7 to 16038, BT7 to 15880
Required: 1
clutch pedal
All BN4 and BN6, BN7 to 16038, BT7 to 15880
Required: 1
BN7 from 16039, BT7 from 15881, all BJ7 and BJ8
Required: 1
clutch pedal
BN7 from 16039, BT7 from 15881, all BJ7 and BJ8
Required: 1
Required: 2
coil spring type with 9" diameter
BN4 and BN6
Required: 1
coil spring type with 10" diameter
BN7 and BT7 (1959-63), BJ7 to engine no. 29F-H4878
Required: 1
coil spring type with 9.5" diameter
BJ7 from engine no. 29F-H4878, BJ8 to engine no. 29K-4107
Required: 1
