Braking system
Braking system
Buy spare parts for "Braking system" of Fiat 500 (1957-1975). ✓ large selection ✓ professional support ✓ fast delivery
Buy spare parts for "Braking system" of Fiat 500 (1957-1975). ✓ large selection ✓ professional support ✓ fast delivery
3 way brake union
More info...
Product number: 541056
500 N, D and early F (1957-66) plus Giardiniera D and early F (1960-66)
3 way brake union
More info...
Product number: 541057
500 late F, L and R (1967-75) plus Giardiniera late F (1967-77)
Banjo bolt
brake hose to front wheel cylinder - M10 x 1.25 fine slope, length: 19 mm
More info...
Product number: 538161
500 (1957-77) • 600 and 770 (1955-69) • 126 (1972-87) • 850 (1964-73)
Bleed screw
wheel cylinder
More info...
Product number: 540959
500 N, D, F, L and R plus Giardiniera (1957-75) • 126 (1972-87) • 600 and Multipla (1955-69) • 850 Berlina, Coupe and Spider (1964–73) • 128 (1969-83)
Bolt
with M8 x 1.25 standard slope and 70 mm length, spanner size: 13 mm, high tensile grade: 8.8
More info...
Product number: 241770
Bolt
with M8 x 1.25 standard slope and 90 mm length, spanner size: 13 mm, high tensile grade: 8.8
More info...
Product number: 540932
Bracket
brake fluid reservoir
More info...
Product number: 540903
500 F to VIN 110F.1799301 (1965-68) and Giardiniera F (1965-77)
Bracket
brake fluid reservoir
More info...
Product number: 540904
500 F, L from VIN 110F.1799302 and R (1968-75)
Bracket
mounting block brake pedal
More info...
Product number: 540917
500 N, D and early F (1957-65) plus Giardiniera D and early F (1960-65)
Brake anchor plate
front axle, LH
More info...
Product number: 540952
500 N, D, F, L and R (1957-75) • 126, 1. Series to June 1974
Brake anchor plate
front axle, RH
More info...
Product number: 540953
500 N, D, F, L and R (1957-75) • 126, 1. Series to June 1974
Brake anchor plate
front axle, LH
More info...
Product number: 540954
500 Giardiniera
Brake anchor plate
front axle, RH
More info...
Product number: 540955
500 Giardiniera
Brake anchor plate
in set for rear axle
More info...
Product number: 540973
500 N, D, F, L and R (1957-75) # 126, 1st Series to June 1974
Brake anchor plate
rear axle, LH
More info...
Product number: 540979
500 Giardiniera
Brake anchor plate
rear axle, RH
More info...
Product number: 540980
500 Giardiniera
Brake drum
front - complete unit with hub
More info...
Product number: 540950
500 N, D, F, L and R (1957-75) • 126, 1st Series to June 1974
Brake drum
front axle
More info...
Product number: 540951
500 Giardiniera D and F (1960-77) • 126, 1st Series from June 1974 on and all 2nd Series models (1976-87)
Brake drum
rear axle
More info...
Product number: 540971
500 N, D, F, L and R (1957-75) • 126, 1st Series to June 1974
Brake drum
rear axle
More info...
Product number: 540972
500 Giardiniera D and F (1960-77) • 126, 1st Series from June 1974 on and all 2nd Series models (1976-87) • 600 D to VIN...2186016 (1960-67)
Brake fluid reservoir
made of plastic, cylindrical
More info...
Product number: 540884
500 D (1960-65) • 600 and 600 D 1st and 2nd Series (1955-65)
Brake fluid reservoir
square variant
More info...
Product number: 540885
500 F to VIN 110F.1732666 plus 500 Giardiniera F to 120F.235218 (1965-68) • 126 with single line braking system (1972-87)
Brake fluid reservoir
square type including filler cap
More info...
Product number: 540886
500 F and L from 110F.1732667 (1968-72), 500 R (1972-75) plus late 500 Giardiniera F (1968-77) • 600 D 3rd Series (1965-69)
Brake fluid reservoir
square variant for dual line brake conversion
More info...
Product number: 540887
500 N, D, F, L and R (1957-75) • 500 Giardiniera (1960-77) • 126, 1. Series (1972-76)
